# model 的模型转向

	var czml = [{
	"id" : "document",
	"name" : "CZML Point - Time Dynamic",
	"version" : "1.0"
	},{
	"id" : "point",
	"availability" :"2012-08-04T16:00:00Z/2012-08-04T16:05:00Z",
	"position" : {
	"epoch" : "2012-08-04T16:00:00Z",
	"cartographicDegrees" : [
	0, 70, 20, 150000,
	100, -80, 44, 150000,
	200, -90, 18, 150000,
	300, -98, 52, 150000,
	]
	},
	"model": {
	"gltf" : "../SampleData/models/CesiumAir/Cesium_Air.glb",
	"scale" : 2.0,
	"minimumPixelSize": 128
	},
	path : {
	resolution : 1,
	material : new Cesium.PolylineGlowMaterialProperty({
	glowPower : 0.1,
	color : Cesium.Color.YELLOW
	}),
	width :3
	},
	}];

	var viewer = new Cesium.Viewer('cesiumContainer', {
	shouldAnimate : true,
	sceneMode: 2,
	});

	viewer.dataSources.add(Cesium.CzmlDataSource.load(czml)).then(function(ds){
	var s = ds.entities.getById("point");
	s.orientation = new Cesium.VelocityOrientationProperty(s.position);
	});

效果如图所示

# billboard 的模型转向

	var czml = [{
	"id" : "document",
	"name" : "CZML Point - Time Dynamic",
	"version" : "1.0"
	},{
	"id" : "point",
	"availability" :"2012-08-04T16:00:00Z/2012-08-04T16:05:00Z",
	"position" : {
	"epoch" : "2012-08-04T16:00:00Z",
	"cartographicDegrees" : [
	0, 70, 20, 150000,
	100, -80, 44, 150000,
	200, -90, 18, 150000,
	300, -98, 52, 150000,
	]
	},
	"billboard" : {
	"scale" : 0.5,
	},
	path : {
	resolution : 1,
	material : new Cesium.PolylineGlowMaterialProperty({
	glowPower : 0.1,
	color : Cesium.Color.YELLOW
	}),
	width :3
	},
	}];

	var viewer = new Cesium.Viewer('cesiumContainer', {
	shouldAnimate : true,
	sceneMode: 2,
	});

	viewer.dataSources.add(Cesium.CzmlDataSource.load(czml)).then(function(ds){
	var s = ds.entities.getById("point");
	s.orientation = new Cesium.VelocityOrientationProperty(s.position);
	s.billboard.alignedAxis = new Cesium.VelocityVectorProperty(s.position, true)
	});

效果如图所示

# billboard 多模型转向

	var czml = [{
	"id" : "document",
	"name" : "CZML Point - Time Dynamic",
	"version" : "1.0"
	},{
	"id" : "point1",
	"availability" :"2012-08-04T16:00:00Z/2012-08-04T16:05:00Z",
	"position" : {
	"epoch" : "2012-08-04T16:00:00Z",
	"cartographicDegrees" : [
	0, 70, 20, 150000,
	100, -80, 44, 150000,
	200, -90, 18, 150000,
	300, -98, 52, 150000,
	]
	},
	"billboard" : {
	"scale" : 0.3,
	},
	path : {
	resolution : 1,
	material : new Cesium.PolylineGlowMaterialProperty({
	glowPower : 0.1,
	color : Cesium.Color.YELLOW
	}),
	width :3
	},
	},{
	"id" : "point",
	"availability" :"2012-08-04T16:00:00Z/2012-08-04T16:05:00Z",
	"position" : {
	"epoch" : "2012-08-04T16:00:00Z",
	"cartographicDegrees" : [
	0, 70, 200, 150000,
	100, 80, 144, 150000,
	200, 90, 118, 150000,
	300, 98, 152, 150000,
	]
	},

	"billboard" : {
	"scale" : 0.3,
	},
	path : {
	resolution : 1,
	material : new Cesium.PolylineGlowMaterialProperty({
	glowPower : 0.1,
	color : Cesium.Color.YELLOW
	}),
	width :3
	},
	}];

	var viewer = new Cesium.Viewer('cesiumContainer', {
	shouldAnimate : true,
	sceneMode: 2,
	});

	viewer.dataSources.add(Cesium.CzmlDataSource.load(czml)).then(ds=>{
	for(var i = 1;i <= czml.length; i++){
	var s = ds.entities.getById(czml[i].id);
	s.orientation = new Cesium.VelocityOrientationProperty(s.position);
	s.billboard.alignedAxis = new Cesium.VelocityVectorProperty(s.position, true)
	}
	});

效果如图所示

# 原文地址

Cesium 基于 czml billboard 的模型转向
